Description
The Shure SM 86 is a cardioid (uni-directional) condenser handheld microphone intended for use in sound-reinforcement and recording applications. The cardioid pattern is effective in reducing ambient, off-axis noise making it a suitable option for use near stage monitors, loud instruments etc. The condenser element requires between 11 to 52 Volts DC phantom power and produces a sensitivity far greater than that of dynamic microphones. Condenser elements provide higher output levels, frequency response, and dynamic range resulting in studio-level sonic quality. A built-in 3-stage shock-mount minimizes handling noise and an internal windscreen reduces noise caused by wind and breath sounds. It’s rugged metal construction is made to withstand the rigors of touring and daily use.
Shure SM86Â Specs
Key Specs
| Form Factor |
Handheld Capsule
|
| Polar Pattern |
Cardioid
|
| Frequency Range |
50 Hz to 18 kHz
|
| Maximum SPL |
147 dB SPL (1 kHz, 1% THD)
|
| Power Sources |
Phantom Power
|
| Color |
Gray
|
Microphone
| Form Factor |
Handheld Capsule
|
| Intended Sound Sources |
Vocals, Speech/Voice-Over
|
| Sound Field |
Mono
|
| Element Type |
1x Condenser
|
| Polar Pattern |
Cardioid
|
| Orientation |
End Address
|
| Circuitry |
Solid-State
|
Performance
| Frequency Range |
50 Hz to 18 kHz
|
| Maximum SPL |
147 dB SPL (1 kHz, 1% THD)
|
| Sensitivity |
-50 dBV/Pa (1 kHz)
|
| Dynamic Range |
124 dB (at Max SPL)
|
| Signal-to-Noise Ratio |
71 dB (at 1 Pa/94 dB SPL)
|
Power
| Power Sources |
Phantom Power
|
| Operating Voltage |
11 to 52 V
|
| Operating Current Consumption |
5.2 mA
|
Physical
| Color |
Gray
|
| Mounting Thread Size |
5/8″-27 Female (3/8″-16 Female with Included Adapter)
|
Packaging Info
| Package Weight |
1.3 lb
|
| Box Dimensions (LxWxH) |
10.2 x 5 x 3.4″
|
